| 规格型号 | 螺纹规格 | 电缆范围 | 开口直径 | 主体外径 | 螺纹长度 | 包装 |
| Spec. | Thread | mm | mm | mm | mm | |
| FRB.TJ.M14 | M14*1.0 | 5-7 | 14 | 20 | 10 | 100 |
| FRB.TJ.M14B | M14*1.0 | 6-12 | 18 | 25 | 11 | 100 |
| FRB.TJ.M22 | M22*1.0 | 11-15 | 22 | 32 | 11 | 50 |
| FRB.TJ.M27 | M27*1.5 | 14-18 | 27 | 36 | 14 | 50 |
| FRB.TJ.M30 | M30*1.5 | 17-23 | 30 | 42 | 14 | 25 |
| FRB.TJ.M36 | M36*2.0 | 22-27 | 36 | 48 | 14 | 20 |
| FRB.TJ.M42 | M42*2.0 | 26-33 | 42 | 54 | 14 | 20 |
| FRB.TJ.M52 | M52*2.0 | 32-41 | 52 | 62 | 14 | 10 |
| FRB.TJ.M58 | M58*2.0 | 40-49 | 58 | 70 | 20 | 5 |
| 欧洲公制 | ||||||
| FRB.TJ.M16 | M16*1.5 | 5-7 | 16 | 20 | 10 | 100 |
| FRB.TJ.M20 | M20*1.5 | 6-12 | 20 | 25 | 11 | 100 |
| FRB.TJ.M25 | M25*1.5 | 11-15 | 25 | 32 | 11 | 50 |
| FRB.TJ.M25B | M25*1.5 | 14-18 | 25 | 36 | 14 | 50 |
| FRB.TJ.M32 | M32*1.5 | 17-23 | 32 | 42 | 14 | 20 |
| FRB.TJ.M40 | M40*1.5 | 22-27 | 40 | 48 | 14 | 20 |
| FRB.TJ.M50 | M50*1.5 | 26-33 | 50 | 54 | 14 | 10 |
| FRB.TJ.M50B | M50*1.5 | 32-41 | 50 | 62 | 14 | 10 |
| FRB.TJ.M63 | M63*1.5 | 40-49 | 63 | 70 | 20 | 5 |
| FRB.TJ.M75 | M75*1.5 | 48-57 | 75 | 78 | 20 | 5 |
