特性
| 规格型号 Spec. | 适配软管尺寸 | 适配硬管尺寸 | 包装 | ||
| Conduit size | Hard tube size | Pcs. | |||
| 公称内径 | 英制尺寸 | 硬管规格 | 适用硬管外径范围 | ||
| FRB.DKJM.10-5/16 | 10 | G5/16" | DN10 | 12.5-13.2 | 50 |
| FRB.DKJM.13-3/8 | 13 | G3/8" | DN12 | 15.6-17.3 | 50 |
| FRB.DKJM.16-1/2 | 16 | G1/2" | DN15 | 18.8-21.5 | 50 |
| FRB.DKJM.20-3/4 | 20 | G3/4" | DN20 | 25.2-27 | 50 |
| FRB.DKJM.25-1 | 25 | G1" | DN25 | 31.6-33.8 | 50 |
| FRB.DKJM.32-1.1/4 | 32 | G1.1/4" | DN32 | 37.9-45.5 | 25 |
| FRB.DKJM.38-1.1/2 | 38 | G1.1/2" | DN40 | 48.8-51.5 | 25 |
| FRB.DKJM.51-2 | 51 | G2" | DN50 | 56.5-65.5 | 10 |
| FRB.DKJM.64-2.1/2 | 64 | G2.1/2" | DN70 | 71.5-79.4 | 10 |
| FRB.DKJM.75-3 | 75 | G3" | DN80 | 84.5-92.5 | 2 |
| FRB.DKJM.100-4 | 100 | G4" | DN100 | 110-118 | 2 |
| FRB.DKJM.125-5 | 125 | G5" | DN125 | 136.5-144.5 | 2 |
| FRB.DKJM.150-6 | 150 | G6" | DN150 | 160.5-169.5 | 2 |
